Stainless Steel Glass Handrail Bracket with Adjustable Arc Saddle - Model C501
Stainless Steel Glass Handrail Bracket with Adjustable Arc Saddle - Model C501
- High Performance: Solid round-bar handrail bracket that carries the handrail load from the post or glass panel to the tube, keeping the railing firm under hand pressure.
- Adjustable Arc Saddle: The arc seat of this handrail bracket swivels to match the tube angle on ramps and stairs, so the same bracket suits horizontal and inclined runs.
- Surface Durability: SUS 201 or SUS 304 stainless steel in satin or mirror finish, polished without burrs; the handrail bracket resists rust in indoor and covered outdoor projects.
- OEM / ODM Supported: Custom bar diameter, projection length, plate drilling and laser logo available; each handrail bracket is packed in an individual box with screws.
* Precision engineered handrail bracket by Gorgeous Hardware.
Technical Specifications
| Product Name | Glass Handrail Bracket / Armrest Support | Model Number | C501 (P104) |
|---|---|---|---|
| Main Material | Stainless Steel SUS 201 / SUS 304 | Standard Colors | Satin Brushed / Mirror Polished |
| Application | Frameless glass railing, glass balustrade and staircase handrail systems | Dimension / Load | 12 x 60 x 60 mm (Bar Dia. 12 mm, Height 60 mm, Reach 60 mm); Base Disc Dia. 42 mm |
| Standard Package | Polybag + Inner Box + Export Carton | Warranty | 3 - 5 Years Guarantee |
| MOQ | 500 PCS (Negotiable) | Lead Time | 30 - 40 Days |
How This Handrail Bracket Is Built
A handrail bracket is the small part that decides whether a railing feels solid or loose, and model C501 is made from a single piece of solid round stainless steel bar, bent and polished as one body. There is no welded joint between the arm and the mounting plate, so the handrail bracket keeps its stiffness even when a heavy person leans on the tube.
The mounting end combines a four-hole plate with a twin disc glass adaptor, which means the same handrail bracket can be fixed to a timber or steel post with screws, or clamped onto a glass panel through the pre-drilled hole. The arc saddle on top is adjustable, so the installer can rotate it to follow the handrail angle on a staircase instead of stocking a second bracket for inclined runs.
Height and reach are both 60 mm, and the base disc measures 42 mm, matching the proportions most glass balustrade drawings call for. Choose SUS 201 satin or mirror for indoor use, or SUS 304 when the handrail bracket will sit on a balcony or near a pool. Laser marking, custom bar diameter and custom plate drilling are all available on this handrail bracket.
International Quality Certifications
Our factory operates under ISO 9001, ISO 14001 and ISO 45001 management systems. Every batch of this handrail bracket is checked by spectrometer, dimension gauge, polishing inspection and neutral salt spray test before packing.
Custom Packaging & On-Time Delivery Workflow
Comprehensive OEM & Branding Solutions
Factory Manufacturing & Production Lines
Global Exhibition & Customer Trust
Frequently Asked Questions (FAQ)
Ready to Upgrade Your Handrail Project?
Contact our engineering sales team for wholesale step-pricing, free samples, and tailored OEM solutions for this handrail bracket. We respond within 8 business hours.
